SCMVAS-M Series - Dataforth High Voltage Attenuator Module

  • SCMVAS-M100
  • SCMVAS-M200
  • SCMVAS-M300
  • SCMVAS-M400
  • SCMVAS-M500
  • SCMVAS-M600
  • SCMVAS-M650
  • SCMVAS-M700
The SCMVAS (Signal Conditioning Modular Voltage Attenuator System) is an analog signal conditioning system designed to safely monitor and accurately measure voltage potentials up to 460VAC (1300V peak-to-peak). These high level voltages are typically found in industrial applications such as induction heaters or electric-motor drive controllers. The system reduces the input signal to a level suitable for interface to data acquisition systems, while at the same time providing various filter characteristics and 1500Vrms isolation.
View options
View All Signal Conditioners

Who We Are

Impulse Embedded is a leading provider of Industrial computing systems and solutions. Our customers rely on us to provide the best embedded computing products and solutions for the challenges presented by today’s industrial demands. Together with our global manufacturing partners we provide world-class innovative embedded computing and automation products and solutions suitable for multiple industrial market sectors.

Not found what you're looking for?

We're only a phone call away. Contact us for more information or for personalised help with your project.

Contact Us
Need Help? Call: +44 (0)1782 337 800
The SCMVAS (Signal Conditioning Modular Voltage Attenuator System) is an analog signal conditioning system designed to safely monitor and accurately measure voltage potentials up to 460VAC (1300V peak-to-peak). These high level voltages are typically found in industrial applications such as induction heaters or electric-motor drive controllers. The system reduces the input signal to a level suitable for interface to data acquisition systems, while at the same time providing various filter characteristics and 1500Vrms isolation.

For each channel of analog input, an attenuator module, SCMVAS-M, pre-conditions the signal which is then filtered, isolated, and converted to a high-level voltage output using an SCM5B30-07 or SCM5B40-07 module. The SCM5B40-07 module with a 10kHz bandwidth is recommended for common 50/60Hz signals low in harmonics where the user is interested in measuring only AC voltage. The SCM5B30-07 module is used for low frequency AC signals below 4Hz. For signals comprised of harmonics or noncoherent content, the SCM5B33 True RMS Input module is recommended. Use of this module provides a DC output that is directly related to input signal power, or the RMS (Root Mean Square) value, allowing true RMS representation of input signals ranging from pulses to complex nonperiodic waveforms. The attenuator and signal conditioning modules have excellent stability over time and do not require recalibration. Overall system accuracy is ±0.06%.

Input signal connections to the SCMVAS-M attenuator module are made using a pluggable terminal block for ease of system assembly and reconfiguration. For safety purposes, the terminal block has a cover over the screws and there are no other exposed high-voltage points on the SCMVAS-M series modules, SCM5B30-07 or SCM5B40-07 module, or the mounting backpanel (SCMVAS-PB8 or PB16).

Delivery & Returns

We offer a range of delivery options to suit your needs, please contact our friendly team for more information.

Dataforth High Voltage Attenuator Module

Please complete the details below to receive your quote

Select the products of this series that you wish to request quantity or project pricing, or lead time information for:

  • SCMVAS-M100

    High Voltage Attenuator Module: ±100V input

    View Product

  • SCMVAS-M200

    High Voltage Attenuator Module: ±200V input

    View Product

  • SCMVAS-M300

    High Voltage Attenuator Module: ±300V input

    View Product

  • SCMVAS-M400

    High Voltage Attenuator Module: ±400V input

    View Product

  • SCMVAS-M500

    High Voltage Attenuator Module: ±500V input

    View Product

  • SCMVAS-M600

    High Voltage Attenuator Module: ±600V input

    View Product

  • SCMVAS-M650

    High Voltage Attenuator Module: ±650V input

    View Product

  • SCMVAS-M700

    High Voltage Attenuator Module: ±700V input

    View Product
